Holloman Air Force Base Private

Airport information

ICAO / IATA

KHMN / HMN

Coordinates

32.8525, -106.1070

Elevation

4,093 ft MSL

Magnetic variation

10E

Sectional chart

ALBUQUERQUE

Airport use

Private

Control tower

Yes

Airspace

Class D

ARTCC

ALBUQUERQUE (ZAB)

Flight service (FSS)

ALBUQUERQUE

NOTAM facility

HMN

Beacon

white-green (SS-SR)

Segmented circle

No

Wind indicator

yes

Activated

1942/06

Distance from city

6 SW

Traffic pattern

Communication frequencies

Nearby navigation aids

Approaches9

• ILS RWY 22 ↗
• ILS RWY 16 Z ↗
• ILS RWY 16 X ↗
• RNAV (GPS) RWY 22 ↗
• RNAV (GPS) RWY 16 ↗
• RNAV (GPS) RWY 34 ↗
• TACAN RWY 16 ↗
• TACAN RWY 22 ↗
• TACAN RWY 34 ↗

Departures

• CLOUD ALPHA FOUR ↗
• CLOUD BRAVO FOUR (RNAV) ↗
• DIEZL ONE ↗
• IZZYY ONE (RNAV) ↗
• OHDEE ONE ↗

Minimums & Hot Spots

• TAKEOFF MINIMUMS ↗
• HOT SPOT ↗

VFR sectional

Open KHMN on the VFR sectional (SkyVector) ↗

Services

Bottled oxygen

NONE

Bulk oxygen

HIGH/LOW

Airframe service

MAJOR

Powerplant service

MAJOR

Ownership & management

Remarks FAA

• ABN UNSERVICEABLE.
• CAUTION: MT TERRAIN 10 NM EAST AND 20 NM WEST.
• CAUTION: UNCTL VEH ON MOVEMENT AREA.
• SERVICE: TRAN ALERT: TRAN ALERT SVC AVBL 1230-0330++ MON-FRI, 1430-2230++ SAT & CLSD SUN & HOL. NO PRIORITY BASIS.
• CSTMS/AG/IMG: CSTMS/ IMG AVBL TO 49 TFW FR OUTSIDE CONUS.
• CAUTION: PORTIONS OF ARPT NOT VIS FR TWR. EXIT RWY 22 ON TWY R HOLD SHORT TWY G.
• CAUTION: COPTER ARR/DEP AVOID HOVER OVER UNPREPARED SFC.
• SERVICE-LGT: GATED THLD LGT ALL RWY.
• BEARING STRENGTH RWY 04-22: ST155 SBTT590 DDT837.
• BEARING STRENGTH RWY 07-25: ST155.
• BEARING STRENGTH RWY 16-34: ST155 SBTT590.
• MISC: STD AETC RSRS APPLIED, NON-AETC ASGN ACFT RQR WRITTEN APVL.
• MISC: RADAR MONITORING NOT AVBL ALL RWY.
• JASU: 2(MD-3) 2(MA-1A) 3(MC-1) 1(MC-1A) 1(M32A-60).
• FUEL: A++.
• FLUID: SP LHOX LOX.
• OIL: O-128-133-148-156 SOAP.
• OPR 1230-0600Z++ MON-THU, 1230-0100Z++ FRI, CLSD WKENDS, HOL, RESILIENCY DAYS, AND TRNG DAYS.
• PPR MUST BE REQ 72 HR PRIOR BUT NO EARLIER THAN 7 DAYS PRIOR TO ARR. CTC AFLD MGMT DSN 572-5411/5412, C575-572-5411/5412. PPR VALID +/- 30 MIN PRIOR/AFTER ETA. EARLY/LATE ARR/DEP MUST BE RE-COORD WITH AFLD MGMT.
• SEE FLIP AP/1 SUPPLEMENTARY ARPT RMK.
• MISC: TWY GOLF WIDTH 150 FT WT BEARING.
• RSTD: HEAVY ACFT SHOULD EXPECT TO LAND RWY 22.
• MISC: WX OBSN SITE LTD 220-350 DEG DUE TO BLDG; NGT OBSN LTD DUE TO HI INST LGT. SVC UNAVBL WHEN AFLD NOTAM CLSD. WX DSN 572-3924/5 C575-572-3924/5. FOR SBY SVC DUR NON-OPR WX HR CTC 25 OWS DSN 228-6674.
• MISC: TRANSIENT ACFT LAST PRIORITY ON REFUELING DUE TO REFUELING MECHANICAL PROBLEMS, EXPECT DELAYS.
• MISC: WX SUPPORT AND AUGMENTED AUTOMATED OBSN AVBL DUR WING FLYING HRS.AUTOMATED OBSN AVBL DURG NON-OPR WX HRS AND DURG AFLD CLOSURE.
• CAUTION: UNCONTROLLED AFLD OPS (UAO) IN EFFECT DURG OUTSIDE PUB AFLD HRS. UAO ONLY AUTH FOR FLYING UNITS LISTED IN HAFBI 11-250. CTC COMD POST DSN 572-7575, C575-572-7575 FOR CURRENT UAO STATUS.
• MISC: VFR HOLD LINES LCTD AT INTERSECTIONS OF RWY 16/34 (4 EA.). ACFT GIVEN CLNC TO LAND OR TAKE-OFF SHALL DISREGARD HOLD LINES AT THE INTERSECTIONS DURG LANDING AND TAKE-OFF ROLL. LAND AND HOLD SHORT OPS NOT AUTH.
• RSTD: HEAVY ACFT PROH FR DEP OR ARR RWY 07/25.
• CAUTION: PAVEMENT MARKINGS THROUGHOUT AFLD FADED & NON-REFLECTIVE.
• CAUTION: USE EXTREME CAUTION, UAS ACFT CONDUCTING STD OPS IN HOLLOMAN AIRSPACE.
• RSTD: 180 DEGS TURNS ON RWY ASPHALT SFC NOT PERMITTED WITHOUT AFLD MGR APVL.
• OPR 1230-0600Z++ MON-THU, 1230-0100Z++ FRI, CLSD WKENDS, HOL, RESILIENCY DAYS, AND TRNG DAYS.REQ TO OPEN THE AFLD ON DAYS WHEN CLSD RQR A MIN OF TWO WKS PRIOR COORD; SEND REQ TO 54OSS.OSAA.AMOPS@US.AF.MIL.
• RWY 34 & RWY 04; AT 2000 FT DIST REMAINING MRK, ONLY 1700 FT OF RWY AVBL.
• ILS/RADAR: RWY 16 ILS AVBL FOR CIR APCH TO RWY 22.
• MISC: AERODROME WX SVC AVBL MON-FRI 0700Z++ UNTIL AFLD CLSD. SVC UNAVBL SAT, SUN, HOL, TRNG/DOWN DAYS UNLESS AFLD NOTAM OPEN. AUTO OBSN AVBL DURG NON-OPR HRS. WX OBSN SITE LTD 220 DEGS - 350 DEGS DUE TO BLDG; NGT OBSN LTD DUE TO HI INTST LGT. WX DSN 572-3924/5 C575-572-3924/5. FOR STBY SVC DURG NON-OPR HRS CTC 25 OWS DSN 228-6674.
• SERVICE-A-GEAR: RWY 04-22 BAK-12B (MID FLD) AND RWY 25 APCH BAK-12B 30 MIN PN. BAK-15 LCTD RWY 16 UNDER-RUN UNSVC. NETS AVBL TO BE RAISED AT PILOT REQ. RWY 34 HOOK BAK-12 B (60 FT OVRN) UNIT IS NOT BI-DIRECTIONAL.
• CAUTION: AFLD HAS HI POTENTIAL FOR FOD FR ENG BLAST, MINIMIZE THRUST DURG GRD OPS.
• MISC: ONLY SINGLE APCH AND FULL STOP LDG AUTHORIZED FOR TRAN ACFT.
• RSTD: RWY 16-34 RSTD TO ACFT WITH WINGSPAN 175 FT OR LESS.
• SERVICE-LGT: RWY 16-34 DIST REM MRK OTS.
• TWY GOLF EDGE LGTS LOCATED 150 FT SOUTH OF TWY GOLF PAVEMENT EDGE INVOF CLSD END OF RWY (EOR) GULF.
• REMARKS-RSTD: CTC AM OPS DSN 572-5411, C575-572-5411 TO SKED.
• UNITS WISHING TO FORWARD DEPLOY TO HOLLOMAN AFB CTC 49 WG/XP DSN 572-7483 FOR WG APVL.
• CAUTION: BIRD HAZARD: WETLANDS AND LAKE LOCATED LESS THAN 1 NM S OF RWY 34 APCH END. BASH PHASE II IN EFF: 1 MAR-31 MAY AND 1 AUG-31 OCT.
• RSTD: ALL ACFT RQRG CARGO AND/OR PAX SVC RQR TO CTC 49 LRS AT DSN 572-0905, C575-572-0905.
• RSTD: NO ENG RUNNING ON/OFF LOADS WITHOUT PRIOR COORD WITH 49 LRS.
• CAUTION: NON-FRANGIBLE SIGN LCTD ON TWY F/TWY E INT LESS THAN 100 FT FR TWY F CNTRLN ON S SIDE.
• SERVICE-A-GEAR: CAUTION: RWY 25 APCH BAK-12 INCREASED STRIKE HAZ TO F-16 CONFIGURED WITH EXTERNAL CNTRLN STORES/TANKS.
• OVERHEAD 6100 FT /300 KT.
• HOOK BAK-12B(B) (1450 FT) HOOK BAK-12B(B) (5287 FT).
• BAK-15 CHAG (2276 FT OVRN) HOOK BAK-12B(B) (1500 FT).
• HOOK BAK-12B (63 FT OVRN) HOOK BAK-12B(B) (1500 FT).
• HOOK BAK-12B(B) (1498 FT).
• HOOK BAK-12B(B) (1630 FT).
• HOOK BAK-12B(B) (1507 FT) HOOK BAK-12B (59 FT OVRN) BAK-15 (NI) UNK (121 FT OVRN).
• PAPI UNUSABLE BYD 8 DEG LEFT OF CENTERLINE.
• PAPI UNUSABLE BYD 8 DEG LEFT OF CENTERLINE.
• 1000 FT X 300 FT CONC THLD, REMAINING RWY IS 8575 FT X 300 FT ASPHALT. RWY MRK 10575 FT X 150 FT.
• FIRST 1000 FT RWY 25 CONCRETE, WEST OF TWY F MIDDLE 75 FT CONCRETE OUTER 37.5 FT WT BRG ASPHALT.
• FIRST 1850 FT RWY 34, FIRST 1700 FT RWY 16 CONCRETE, MID 8581 FT ASPHALT.
